ASUS PRIME Z390-P-42243
  • ASUS PRIME Z390-P-42243
  • ASUS PRIME Z390-P-42244
  • ASUS PRIME Z390-P-42245
  • ASUS PRIME Z390-P-42246

ASUS PRIME Z390-P

256,81 лв.
С вкл. данък
ASUS Z390 4xDDR4 4xSATA3 RAID HDMI DP 2xM2 GLAN 2xPCIEx16 4xPCIEx1
Asus
90mb0xx0-m0eay0

ASUS PRIME Z390-P

Техническо описание

Warranty
36 Months
Процесор
Intel Socket 1151 9th / 8th Gen Intel Core™, Pentium Gold and Celeron Processors, Supports Intel 14 nm CPU, Supports Intel Turbo Boost Technology 3.0
Тип
4 x DIMM, Max. 64GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered MemoryDual Channel Memory Architecture, Suppor
LAN
Realtek RTL8111H, support LANGuard
Чипсет
Intel Z390
Видео адаптер
Integrated Graphics Processor- Intel UHD Graphics support, Multi-VGA output support : HDMI/DisplayPort ports, - Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz, - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz, Supports Intel InTru™
Форм фактор
ATX
Audio
Realtek ALC887 8-Channel High Definition Audio CODEC, - Supports : Jack-detection, Front Panel Jack-retasking, Audio Feature : - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path., - Audio Shielding: Ensures pr
Размер на флаш памет
Intel Z390 Chipset :1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA - PCIE 3.0 x 4 mode)1, 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA - PCIE 3.0 x 2 mode), 4 x SATA 6Gb/s port(s), Suppor
I/O
1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x DisplayPort, 1 x HDMI, 1 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 2 Type-A,, 4 x USB 3.1 Gen 1 Type-A,, 3 x 8-channel Audio I/O
Expansion Slots
1 x PCIe 3.0/2.0 x16 (x16 or x8+x4+x4), 1 x PCIe 3.0/2.0 x16 (max at x4 mode), 4 x PCIe 3.0/2.0 x1, 1 x M.2 Socket (Key E), supports type 2230 Wi-Fi/BT and Intel CNVi (Integrated Wi-Fi/BT) module, For 3 SSD on CPU support, install a Hyper M.2 X16 card (so
OS
MS Windows
Connectors
1 x Lighting Control RGB Strip Header(s), 2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s), 1 x USB 2.0 1-port connector(s) support(s) additional 1 USB 2.0 port(s), 1 x USB 2.0 connector(s) support(s) additional 2
BIOS
128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence
CPU сокет
LGA1151
