MSI B450I GAMING PLUS AC

Техническо описание

Warranty

36 Months

LAN

1 x Realtek 8111H Gigabit LAN controller,Intel Dual Band Wireless-AC 3168 module

Audio

Realtek ALC887 Codec

Other

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

Manufacturer

Micro-Star INTL CO., LTD.

I/O

USB 2.0, DisplayPort, LAN,Wi-Fi / Bluetooth,HD Audio Connectors, PS/2 Combo Port,HDMI,HDMI, USB 3.1 Gen1,USB 3.1 Gen1

Expansion Slots

1 x PCIe 3.0 x16 slot

OS

Support for Windows 10 64-bit,Support for Windows 7 64-bit

Connectors

1x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector,4 x SATA 6Gb/s connectors, 1 x USB 2.0 connector (support additional 2 USB 2.0 ports),1 x USB 3.1 Gen1 connectors (support additional 2 USB 3.1 Gen1 ports),1 x 4-pin CPU fan connector,

Memory type

2 x DDR4 memory slots, support up to 64GB,Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC),Supports2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)

Storage

1 x M.2 ports (M2_1, Key M),supports PCIe 3.0 and SATA 6Gb/s 2280 storage devices,4 x SATA 6Gb/s ports

Form factor

Mini-ITX Form Factor,17.0 cm x 17.0 cm

Graphics

1 x HDMI 1.4 port,1 x DisplayPort, Requires Processor Graphics

Model

B450I GAMING PLUS AC

Chipset

AMD B450 Chipset

CPU's supported

Supports 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics Desktop Processors for Socket AM4

Socket

AM4
