ASROCK B550 PG VELOCITA /AM4

Техническо описание

Warranty

36 Months

LAN

- 2.5 gigabit lan 10/100/1000/2500 mb/s, - dragon rtl8125bg, - supports phantom gaming lan software, - smart auto adjust bandwidth control, - visual user friendly ui, - visual network usage statistics, - optimized default setting for game, browser, and st

Audio

- 7.1 ch hd audio with content protection (realtek alc1220 audio codec), - premium blu-ray audio support, - supports surge protection, - 120db snr dac with differential amplifier, - ne5532 premium headset amplifier for front panel audio connector (support

I/O

- 2 x antenna mounting points, - 1 x ps/2 mouse/keyboard port, - 1 x hdmi port, - 1 x optical spdif out port, - 1 x usb 3.2 gen2 type-a port (10 gb/s) (supports esd protection), - 1 x usb 3.2 gen2 type-c port (10 gb/s) (supports esd protection), - 2 x usb

Expansion Slots

Amd ryzen series cpus (matisse), - 2 x pci express x16 slots (pcie1: gen4x16 mode, pcie3: gen3 x4 mode), amd ryzen series apus (renoir), - 2 x pci express x16 slots (pcie1: gen3x16 mode, pcie3: gen3 x4 mode), - 2 x pci express 3.0 x1 slots, - supports amd

OS

- Microsoft Windows 10 64-bit

Connectors

- 1 x spi tpm header, - 1 x power led and speaker header, - 2 x rgb led headers, - 2 x addressable led headers, - 1 x cpu fan connector (4-pin), - 1 x cpu/water pump fan connector (4-pin) (smart fan speed control), - 5 x chassis/water pump fan connectors

BIOS

- 256mb ami uefi legal bios with gui support, - supports "plug and play", - acpi 5.1 compliance wake up events, - supports jumperfree, - smbios 2.3 support, - cpu, cpu vddcr_soc, dram, vppm, vtt_ddr offset, cpu vdd 1.8 voltage multi-adjustment

Memory type

- dual channel ddr4 memory technology, - 4 x ddr4 dimm slots, - amd ryzen series cpus (matisse) support ddr4 4733+(oc) / 4666(oc) / 4600(oc) / 4533(oc) / 4466(oc) / 4400(oc) / 4333(oc) / 4266(oc) / 4200(oc) / 4133(oc) / 4000(oc) / 3866(oc) / 3800(oc) / 37

Storage

- 6 x sata3 6.0 gb/s connectors, support raid (raid 0, raid 1 and raid 10), ncq, ahci and hot plug, - 1 x hyper m.2 socket (m2_1), supports m key type 2230/2242/2260/2280 m.2 pci express module up to gen4x4 (64 gb/s) (with matisse) or gen3x4 (32 gb/s) (wi

Form factor

- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm, - 2oz Copper PCB

Graphics

- integrated amd radeon vega series graphics in ryzen series apu, - directx 12, pixel shader 5.0, - споделена памет с оригиналния продукт 2gb. максималната обща памет поддържа до 16 gb., - supports hdmi 2.1 with max. resolution up to 4k x 2k (4096x2160) @

Chipset

- AMD B550

CPU's supported

- supports amd am4 socket ryzen 3000, 4000 g-series and 5000 series desktop processors, - digi power design, - 14 power phase design
